Use case: Solution | Apps: CamOverlay App, CamScripter App
Segment: Security & industry applications
Keywords: embedded graphics, access system, control room, integration, demo example
We have integrated the AXIS P3228-LV Network Camera with the Axis A1001 door controller to graphically display information about the user requesting access to the door directly in the H.264 video stream from the camera.
This connectivity provides an easy visual inspection of entering persons at the surveillance site in real time, and simultaneously enables the same control in recordings. The graphics are inserted into the image directly in the camera, becoming part of the H.264 video stream generated by the camera and making the integration much easier.
System components in the video:
System Wiring Diagram
About the CamScripter App
The CamScripter App is a unique application that allows you to run micro apps directly on an Axis IP camera. You can choose from presets or tailor-made micro apps. The application runs inside an Axis network camera. In combination with the CamOverlay App, it allows you to embed any data from any source into your video.
Micro app for Door controller
The application has its own user interface (see picture below) where you can set the IP address, access details to Door controller, graphics position displayed in the camera image and manage photos of individual users registered in the Door controller. In our application, photos are stored on the SD card directly in the camera, but with a little adjustment can be read from a different source, such as your VMS server.
The application is freely downloadable together with its source code on our GitHub account here: https://github.com/CamStreamer
User interface of micro app
Live view of the camera
About the CamOverlay App
CamOverlay is a smart application that displays dynamic overlay graphics in the video directly on the Axis IP camera. The setup is easy. You can choose from preset overlays, such as a weather widget, info ticker line, custom transparent images, pictures from another camera and graphics related to PTZ positions. The application is also used to get graphics based on CamScripter App queries.
Check How to set tutorial video here.
Download PDF brochure here.
For more information please contact us.
